Framed Circular Glass 60 cm

  • Sizes range from 600mm to 1500mm diameter.
  • Four stocked sizes with 5-day delivery.
  • Custom sizes upon request.
  • Features 31.5mm thick Low-E insulated double glazing.
  • 6mm toughened exterior glass.
  • Cavity filled with 90% Argon for insulation.
  • Inner layer includes 7.5mm laminated soft coat Low E glass with a 1.5mm PVB interlayer.
UGS : circular-glass-600

 1.636,30 2.180,80

12 People watching this product now!
  • Skylights1 Entrepôt

A retirer aujourd'hui

Gratuit

  • Livraison express 1-2 jours

Notre coursier livrera à l'adresse indiquée

2-3 jours

Gratuit

  • Livraison standard

Notre courrier livrera à l'adresse indiquée

3-5 jours ouvrables

Gratuit

  • Garantie 10 ans
  • Livraison gratuite pour toute commande supérieure à £2000

Payment Methods:

Description

Discover the elegance of Circular Glass

Circular Glass, a high-quality round rooflight, provides sleek aesthetics and comes in various sizes, suitable for fitting onto a builder’s upstand or with an integrated insulated GRP kerb. This modern glazing solution offers a neat look inside and a slender profile outside, maximizing natural light in modern spaces.

Framed Circular Glass Brochure.pdf

Framed Circular Glass Datasheet.pdf

Benefits

  • Contemporary, chic circular glass rooflight design.
  • Sleek aluminium frame with a RAL 7016 powder coat finish.
  • Exceptional thermal efficiency due to an isolated frame and double glazing, achieving a Ur value down to 1.16 W/m²K.
  • Enhanced safety with a laminated inner pane, meeting CWCT TN67 for class 1 roofs and Class B non-fragile standards according to ACR[M]001.
  • 10-year warranty option.
  • Prefabricated insulated GRP Kerb option for easy installation.
  • Size range from 600mm to 1500mm, with custom sizes on request.
  • Glazed unit installation is straightforward, attaching directly to an existing builder’s upstand.
  • The Insulated GRP Kerb ensures a 150mm termination height for roof membranes.
  • The glazing consists of a 31.5mm thick Low-E insulated double glazed glass unit, with a 6mm toughened outer layer, a 90% Argon-filled cavity, and a 7.5mm laminated soft coat Low E inner layer with a 1.5mm PVB interlayer.

Features

  • Multiple sizes available, including 4 standard options with 5-day delivery.
  • Can be directly mounted to a builder’s upstand or used with a durable insulated GRP kerb for both new constructions and renovations.

Pitch Requirements

Rooflight should be installed at a minimum pitch of 2° to ensure adequate water runoff.

Measuring Guide for fitting to builders upstand

Measure external builders upstand

Acceptable tolerance:

  • Fixed rooflight = rooflight size +20 / -0mm

Measuring Guide for domes with GRP kerb

Measure internal roof opening

KERB

Framed Circular Glass can be supplied as a glazing-only option or complete with a robust, insulated GRP kerb.

Framed Circular Glass on Builders Upstand

Framed Circular Glass with GRP Kerb
